features：
※The bright VGA/4 ¾ set reading resolution
※Probe automatic calibration / host automatic memory operation mode
※Basic resolution：0.01mT
※Measuring accuracy： Reading of±0.3%
※Display unit：Gs，T，A/M
※RS-232C /BNC interface
※Max / min / peak / Valley / hold / interface lock
※Data storage (automatic / manual) / storage data reading
※Automatic zero, automatic, manual measurement range
※Zero setting / relative measurement mode
※Baud rate adjustment
※Threshold setting (upper and lower limits) and alarm
※Time and brightness setting
※Acquisition rate adjustable
※Dozens of different probes can be selected
specifications：
specifications | Name | parameter | Unit | Remarks |
DC Measurement specifications
| channel | 1 |
|
|
Display refresh rate | 3 | Times/sec |
|
resolution | 0.01 | mT | (0.1Gs) |
range | 0-3 | T | (30kGs) |
accuracy | Reading of ±0.3 | % | Range of ±0.05% |
AC Measurement specifications
| resolution | 0.1 | Gs | 0.01mT |
accuracy | Reading of ±1 | % | Range of±0.5% |
| Range | 0-3 | T | (30kG) |
Frequency measurement range | 2-50000 | Hz |
|
Probe parameters | temperature coefficient | Reading of ±0.03% | %/oC |
|
Probe function | Automatic recognition |
|
|
Probe connector | DB15
|
|
|
Probe compatibility
| BLDHALL |
|
|
